dedicated printed circuit board assembly facility at columbia tech
SMT assembly line for screen printing pcba components
solder paste applied via screen printing machine
solder paste inspection machine for pcba testing
A part feeder supplies components from reels for placement on a printed circuit board
A part feeder supplies components from reels for placement on the board
A machine operator reviews component placement
3D X-Ray Inspection machine
Automated supply dispensers located throughout production areas expedite production by making tools and basic supplies accessible and traceable.
Printed circuit board assembly testing and inspection.
Large through-hole components are placed by hand
A wave solder machine solders the hand inserted through-hole parts
A freshly soldered printed circuit board is removed from the wave solder machine
Delicate components are soldered individually by a trained and certified solder technician
Columbia Tech exclusively uses no-clean flux lead or lead free as specified
skilled Test Technicians trouble shoot boards to resolve any issues
Columbia Tech test technician performs a final inspection of PCB assembly
Inspector reviews the printed circuit board for defects and compliance to documentation.
An inspector stamps each board with their unique stamp for verification
